ShockFlo® A6 Tesla to J1772 EV Adapter

First, it's helpful to understand that home electrical circuits have a maximum total current capacity, usually around 100 amps or 50 amps.

Additionally, the currents from separate branch circuits all add up to the total current on the main circuit. So if you set your EV charger to 40 amps, that means the rest of your home circuits combined can't exceed 60-100 amps. But some appliances like clothes dryers or space heaters use around 20 amps. This means it's easy to overload your main circuit when running the EV charger and other high-power devices.

That's why the LCD screen allows you to monitor the charging current in real-time. And by estimating your overall load, you can adjust the EV charger lower when using other large appliances. You can also use the delayed charging feature of the ShockFlo G1 Portable EV Charger to avoid overlapping high loads, starting charging after you go to sleep. This helps prevent circuit overload.

What's more, the temperature readout on the LCD screen guards against potential overheating hazards during operation.

41*31*12cm. We have left 20% extra space to make it easier to fit the charging cables inside the Carrying Storage Bag.

To use the maximum current of the G1 portable charger, you need to change your circuit environment and install NEMA 14-50 so that you can set up level 2 charging (32 amp or 40 amp, 240 volts).
Here are the details: Circuit Breaker: 50 amp Operating Current: 32 amp / 40 amp Conductors: 6 AWG, Copper Wire Only. Upsize wiring for installations over 150 feet
For more information on how to install a Level 2 EV charger, watch the video below.
https://youtu.be/sMX1JdfF1_g

Press the "Delay" button and decide when you would like to begin charging the car.

There's a controller bracket inside the package making it easy to install it onto the wall.

We recommend charging with power off and using it in a cool or fire-proof environment. 1. The product should be placed out of the reach of children 2. It is forbidden for minors to operate alone 3. After receiving the product, please follow the product list to check if there is any omission 4. Do not use this product in water 5. The internal structure of the product is precise, please do not disassemble it without the support of professionals 6. This product is only used for electric vehicle charging, please do not use it in other occasions, including traction, bundling, etc. 7. If any part of the product is damaged, please do not use it with power on 8. Please unplug it when charging is complete

The excessive temperature in summer may trigger the temperature rise protection mechanism. When the temperature of the charger reaches 55°C, it will automatically adjust the current and power to stabilize the temperature. If it exceeds 80°C, the device will be power off automatically to protect your personal and property safety. It is recommended to check the charging status in time.
